Altis Sigma 25kW Lightweight Off-Road Electric Dirt Bike (98V Hairpin Motor, 35Ah ALTIS PowerPack, 601 Nm Torque

Dominate extreme singletrack trails, dirt tracks, and rugged backcountry with the Altis Sigma 25kW Lightweight Off-Road Electric Dirt Bike. Engineered as a high-performance, electric alternative to traditional 100cc–200cc gas motocross bikes, the Altis Sigma harnesses an advanced 98V high-efficiency Hairpin electric motor generating a massive 25 kW of peak power and an astronomical 601 Nm (443 ft-lbs) of wheel torque. Powered by the proprietary high-voltage 35Ah ALTIS PowerPack, this electric pit bike accelerates to speeds exceeding 80 KM/H (50+ MPH) with explosive throttle response.

⚠️ High-Output Off-Road Performance & Chassis Guidelines

IMPORTANT POWERTRAIN & CHASSIS SPECIFICATIONS:

• 25 kW Peak Power & 98V Hairpin Motor: State-of-the-art hairpin winding technology delivers extreme power density, rapid thermal dissipation, and instant torque delivery across the entire RPM band.

• 601 Nm (443 ft-lbs) Wheel Torque & Heavy-Duty 428H Drive Chain: Built to withstand brutal acceleration and high-impact off-road launching using a heavy-duty 428H motorcycle chain.

• Linkage Rear Suspension System: Features 85mm of rear suspension travel paired with a progressive linkage system and high-strength spoked wheels with lightweight aluminum rims.

• Fast US Warehouse Fulfillment: Shipped directly from regional US warehouses for rapid delivery, zero import hassles, and reliable domestic customer service.

🚀 Key High-Performance Features

• High-Efficiency 98V Hairpin Motor: Air-cooled design provides maximum thermal efficiency and continuous high-kW output under aggressive riding conditions.

• Proprietary 35Ah ALTIS PowerPack: High-density 98V lithium-ion battery engineered for high-discharge performance and long off-road moto sessions.

• High-Current AC Fast Charging: Includes a high-output AC 110V/12V 12.5A fast charger for rapid battery replenishment between trail sessions.

• Competition-Grade Wheel & Tire Package: Heavy-duty aluminum rims laced with heavy-gauge spokes handle high-impact jumps, rock gardens, and deep ruts.

• Progressive Suspension Architecture: High-travel front fork and 85mm linkage rear shock absorb severe track impacts and high-speed trail chatter.

📊 Technical Specifications Matrix

Product Description

CHASSIS

* Weight (with battery): 88 kg
* Wheelbase: 1285 mm
* Front brake disc diameter: 260 mm
* Rear brake disc diameter: 220 mm
* Chain: 428H
* Frame design: Aluminium alloy forging
* Ground clearance: 300m
* Seat height: 840 mm
* Steering head angle: 26 °
* Suspension travel (front): 200 mm
* Suspension travel (rear): 85 mm with linkage
* Rear Wheel travel: 200mm with linkage
* Wheels: Spoked wheels with aluminum rims

Motor

* Max. power: 23 kW (31HP)
* Torque: 601 Nm (443 ft-lbs)
* Battery: Lithium-Ion ALTIS PowerPack
* Battery capacity: 35 Ah
* Charging input: AC110V/112V12.5A
* Charging time 20%-100%: 180 min.
* Charging time 20%-80%: 120 min.
* Cooling: Air-cooled
* Energy content: 3.402 kWh
* Electric motor: 98V - Hairpin motor

MODEL HIGHLIGHTS

1)MODEL HIGHLIGHTS: 97.2V 35Ah (3402Wh) 2)Samsung 50S battery Cells (Greenway Battery Pack) Charging time (20% - 80%): 2 Hours

3)23kw(31HP) peak Hairpin Motor (Automotive standard)

4)Adjustable off-road air-spring suspension

5)3.5" TFT display with NFC feature

6)5levels of regenerative braking

7) Headlight & Taillight (w/brake light) switch 8) Heavy-duty disc brake CST off-road tires

Specification

item	value
Model	2026 SIGMA MX
Max. Speed	> 80km/h
Place of Origin	jiangsu
Motor	Other
Brand Name	Altis
Model Number	sigma
Max. power	23 kW (31HP)
Torque	601 Nm (443 ft-lbs)
Battery	Lithium-Ion ALTIS PowerPack
Battery capacity	35 Ah
Charging input	AC110V/112V12.5A
Chain	428H
Electric motor	98V - Hairpin motor
Cooling	Air cooled
Wheels	Spoked wheels with aluminum rims
Suspension travel (rear)	85 mm with linkage

📋 Ideal Applications

• Aggressive Trail & Motocross Riding: 25 kW peak power and instant 601 Nm torque deliver uncompromised off-road acceleration and hill-climbing power.

• Singletrack & Backcountry Exploration: Silent electric operation lets you explore remote trails without noise disruption.

• Gas-to-Electric Pit Bike Upgrades: Replaces traditional 100cc-200cc gas dirt bikes with zero emissions, instant throttle response, and minimal drivetrain maintenance.

📦 Package Contents

• 1 x Altis Sigma 25kW Lightweight Electric Dirt Bike

• 1 x 35Ah ALTIS High-Voltage PowerPack

• 1 x High-Current AC 110V 12.5A Fast Charger

• 1 x Owner's Operating & Maintenance Manual

• 1 x Assembly Tool Set & Drivetrain Service Kit

Unleash 25kW of instant hairpin-motor power and 601 Nm of torque on the trails! Select your options above, click Add to Cart, and order your Altis Sigma today!
